SW-VM series

Water injected oil free technology adopting pure water as the lubricating medium instead of the oil to achieve the maximum efficiency and 100% oil free screw air compressor. Certified by TÜV Rheinland Germany according to ISO 8573-1 Class 0

Two-Stage compression process at the water lubricant compressor are split on 1st stage and 2nd stage single screw airend. Each single screw airend is direct driven by the permanent magnet motor with VSD inverter. This is the best configuration for two-stage air compression technique to achieve the highest level of efficiency and energy saving air compressor. Each stage supporting by dedicated air-water separation tank, water filter, protection device and plate fin heat exchanger.

Single screw
Water lubricant
92 to 310 kw
10 - 50 m³/min
8 - 40 ba
